管道外壁自動噴砂機
◆可用于條件 Applicable scope
管類(lei)部件,如:不銹鋼(gang)管、園鋼(gang)、螺桿式、螺桿式、玄幻園柱體、圓筒形類(lei)、園柱體型軸類(lei)零件;使用雙槍(可按符合要求多槍)及(ji)漩風式除塵系統器和光電子感受(shou)到的功能,提高了了生育速率(lv)及(ji)小臭的減小了維(wei)修保養率(lv)。 (此型號需指(zhi)定)
The kind of pipe workpieces, such as: steel pipe, round steel, bars, screw, large cylindrical, cylinder, round the plant; Adopt double gun (according to demand more gun) and new filter and light electricity function, improve the production efficiency and reduce the maintenance rate. (the model need to customize)
◆一般技巧規格 Main technical parameters
|
刷卡機技術參數 Model |
STR-1500管道外壁自動噴砂機 |
STR-1800輥傳動雙槍自動噴砂機 |
|
運作艙尺寸 Working class size(mm) |
1000×900×900 |
1800×900×1000 |
|
空機長寬 Complete machine size(mm) |
1200×900×2900 |
1900×900×2900 |
|
文件壓縮冷空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
電原 Power |
220v 50Hz |
220v 50Hz |
|
變頻電機馬達可控硅調壓器 Governor |
250W×2 |
250W×2 |
|
隔離器高壓電機 Separator motor |
380v 50Hz 4kw |
220v 50Hz 1.1kw |
|
提取器風速 Air separator |
35m3/min |
35m3/min |
|
產品毛重 Machine weight |
900kg |
900kg |
